SALIENT FEATURES : LINER VALVES
l
l
Sealing ribs on end faceswith enough protrusion to ensure drop-tight end face joints.
l
Sturdy& long shaft bearings ensuring precise rotation of the disc assembly in the body.
l
Double Shaft seal which precludes leakage possibility.
l
SturdyDisc-shaft connection.
l
Robustbacklash-freeHandLevermechanismwithout thepossibilityofover-traveldue toprovisionof in-built,positive travel limitstops.
l
Electrical / Pneumatic actuator drives optionally available.
Liner locked in precisionmachined grooves in valve body.
SPECIAL FEATURES : LINER VALVES
l
Optimized liner dimensions ensuring efficient sealing performance.
l
Critically controlled interference between the rubber liner & the Disc sealing surface ensuring leak-tightness & lower operating
torque at the same time leading to long seal life.
l
Stainless Steel Investment cast Disc as a standard scope of supply.
NOTES :
l
All dimensions are in mm unless otherwise specified.
l
Views and dimensions are typical & illustrative. They may change with design modifications.
l
For larger sizes / HOPD dimensions & Special requirements, contact our Marketing Dept.
l
Pressure Ratings as per PN 6 / 10 / 16 / 25 & Class Ratings as per AWWA C-504.
WAFERLINERLUGGEDTYPEWITHHANDLEVER
WAFERLINERLUGGEDTYPEWITHMANUALGEARBOX
